Überhitzungsschutz

Überhitzungsschutz

Anwendungsbereich des Miniatur-Überhitzungsschutzes BH-TB02B

(1) Der Akkupack kann die Sicherung wiederherstellen,

⑵ shaded pole motor thermal protector,

⑶ AC motor and water pump thermal switch,

⑷ Fluorescent lamp ballast temperature switch,

⑸ Transformer temperature control switch,

⑹ Electric heating appliance temperature limiter,

⑺ Portable power tool thermostat,

⑻ Ballast over temperature protector,

⑼ Micromotor temperature protector,

Merkmale und Vorteile des Miniatur-Wärmeschutzes BH-TB02B

⑴ Small size, easy to install

⑵ Low internal resistance, less than 25 mΩ

⑶ Quick-action bimetal, fast response

⑷ Life expectancy is more than 10,000 times

⑸ Anti-vacuum dipping process

⑹ Current temperature double protection

⑺ Leads can be customized according to requirements

⑻ Can replace imported products such as SENSATA 4MM/6MM, PEPI, ISUZU IP405/505

⑼ There are two types of normally closed and normally open

⑽ When using contact temperature sensing installation, the product should be close to the installation surface of the controlled appliance

⑾ When installing, do not force the casing to collapse or deform it, so as not to affect its performance

Anmerkungen: Kunden können die Schale und den Draht nach unterschiedlichen Bedürfnissen auswählen.

Technische Parameter des Miniatur-Wärmeschutzes BH-TB02B

⑴ Product size: temperature sensor head 13.55.42.4mm

(2) Kontaktkapazität: 10K (4A/12VDC 3A/24VDC 3A/120VAC 2A/250VAC)

(3) Betriebstemperatur: 30155 Grad

⑷ Accuracy: ±5 ±3 ±1 degree

⑸ Internal resistance: less than 25 mΩ
